Epson TM-T81III Technical Reference Guide

59
Appendix
Appendix
Product Specifications
*1: According to our operation conditions
Printing method Thermal line printing
Paper feed speed Approx. 200 mm/s {approx. 7.88"/s}
(continuous paper feeding with the Feed button)
Cutting Method Partial cut (cutting with one point at center left uncut)
Interface USB: USB 2.0 Full-speed (12 Mbps)
Ethernet: 10BASE-T/100BASE-TX
Serial: RS-232
Buffers Receive buffer 4 KB/45 bytes (selectable using the memory switches)
Downloaded buffer Approx. 12 KB
(both for user-defined characters and downloaded images)
NV graphics data 256 KB
Downloaded graphics data 208 KB
Barcode/two-dimensional symbol/
composite symbol printing
UPC-A, UPC-E, JAN 8 (EAN 8), JAN 13 (EAN 13), CODE 39,
ITF, CODABAR (NW-7), CODE 93, CODE 128, GS1-128,
GS1 DataBar Omnidirectional, GS1 DataBar Truncated,
GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional,
GS1 DataBar Limited, GS1 DataBar Expanded,
GS1 DataBar Expanded Stacked, PDF417, QR CODE,
MaxiCode, Composite Symbology
Drawer kick connector drive function 2 drives
Power supply Rated voltage: 100 to 240VAC 50/60Hz, Rated current: 1.0 A
AC power consumption
(100 to 230 V/50 to 60 Hz)
*1
Operating Approx. 27.8 W
Standby Approx. 0.96 W
Life
*2
Mechanism 15 million lines
Thermal head 100 km
Autocutter 1,500,000 cuts
MTBF
*3
360,000 hours
MCBF
*4
60,000,000 lines
Temperature/humidity Operating: 5 to 45°C {41 to 113°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions (H × W × D) 140 × 149 × 192 mm {5.51 × 5.87 × 7.56"}
Mass Approx. 1.5 kg {3.31 lb} (roll paper excluded)

Epson TM-T81III Specifications

General

Print Method	Thermal line printing
Resolution	203 x 203 dpi
Paper Width	79.5 ± 0.5 mm
Auto Cutter	Yes
Interface	USB, Serial
Dimensions	140 x 199 x 146 mm
Paper Thickness	0.06 to 0.08 mm
