TM-T82 User’s Manual 17
English
Specifications
Mbps: megabits per second
*1: The values are those when the paper width is changed to 58 mm by installing the 58-mm width paper guide plate and
making the paper width setting with utility software for the TM-T82.
For how to install the 58-mm width paper guide plate, see “Changing the Paper Width” on page 13.
*2: Be sure to use a safety-standards-applied power source that meets the following specifications.
Rated output: 24 V/1.5 - 10.0 A, Maximum output: 240 VA or less.
80 mm paper width 58 mm paper width
*1
Printing method Thermal line printing
Printing speed 150 mm/s {5.91"/s} max.; 40 lps (3.75 mm {0.15"} feed)
Ladder bar code and 2D symbol: 100 mm/s {3.94"/s}
The above speed values are approximate.
The values are when the printer prints with density “Normal” at 25°C {77°F}.
Speed is adjusted automatically depending on the voltage applied and head
temperature.
Roll paper
(single-ply)
Width 79.5 mm ± 0.5 mm {3.13" ± 0.02"} 57.5 mm ± 0.5 mm {2.26" ± 0.02"}
Diameter Maximum outside diameter: 83 mm {3.27"}
Spool Spool diameter: Inside: 12 mm {0.47"}; Outside: 18 mm {0.71"}
Interface Serial (RS-232)/Parallel (IEEE1284)/USB [Compliance: USB 2.0, Communication
speed: Full-speed (12 Mbps)]/Ethernet (10BASE-T/100BASE-TX)
Power supply
*2
DC + 24 V ± 7%
Current
consumption
Ready Mean: Approx. 1.5 A
Sleep Mean: Approx. 0.1 A
Temperature Operating: 5 to 45°C {41 to 113°F}
Storage: –10 to 50°C {14 to 122°F}, except for paper
Humidity Operating: 10 to 90% RH
Storage: 10 to 90% RH, except for paper
Overall dimensions 140 × 199 × 146mm {5.51 × 7.83 × 5.75"} (W × D × H)
Weight (mass) Approx. 1.7 kg {3.74 lb}

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson TM-T82 and is the answer not in the manual?

Epson TM-T82 Specifications

General IconGeneral
Print MethodThermal line printing
Paper Width80 mm
Paper Roll Diameter83 mm
Print Resolution203 dpi
InterfaceUSB, Serial
CutterAutomatic cutter
Dimensions199 x 146 mm
Power SupplyAC adapter (included)
