Epson TM-T82 User Manual

TM-T82 User’s Manual 9
English
Note:
You can install the printer so that the roll paper cover is upright to the mounting surface
using the included wall hanging bracket.
1. Attach the control panel label for vertical installation on the roll paper cover.
2. Install the wall hanging bracket on the printer, and fix it using 2 included screws.
3. Attach 2 rubber feet in the rectangular indents in the printer case, and attach 2 rubber
feet within the scribed line on the hanging bracket.
4. Place the printer with the wall-hanging-bracket-side down.
1
2
3
Wall hanging
bracket
Rubber feet
Control panel label for
vertical installation
207 mm
{8.15"}

Epson TM-T82 Specifications

General

Print Method	Thermal line printing
Paper Width	80 mm
Paper Roll Diameter	83 mm
Print Resolution	203 dpi
Interface	USB, Serial
Cutter	Automatic cutter
Dimensions	199 x 146 mm
Power Supply	AC adapter (included)
