TM-U295/TM-U295P User’s Manual 9
English
TM-U295/TM-U295P Specifications
*1: Be sure to use a safety-standards-applied power source that meets the following specifications.
Rated output: 24 V/2.0 - 10.0 A, Maximum output: 240 VA or less
Printing method Impact dot matrix, 7-pin shuttle type
Printing direction Unidirectional
Characters per line
(default)
5 × 7 font: 35; 7 × 7 font: 42
Character matrix 5 × 7 with 1-dot spacing (normal dots)
7 × 7 with 3-dot spacing (half dots)
Character size 5 × 7 font: 1.6 × 2.9 mm
7 × 7 font: 1.3 × 2.9 mm
Number of characters Alphanumeric characters: 95; International characters: 32
Extended graphics: 128 ´ 4
Print speed 1.9 to 2.3/lines/sec. (both 5 × 7 and 7 × 7 fonts)
Paper feed speed Approx. 12.5 lines/second (52.9 mm/second)
Line spacing (default) 4.23 mm
Paper types Normal, pressure-sensitive, and carbon-copy
Paper size 80 × 69 mm (W × L) to 182 × 257 mm (W × L)
Total thickness Single-ply: 0.09 to 0.25 mm
Copy paper: 0.09 to 0.35 mm
Number of copies Original + 1 or 2 copies at 5 to 40°C
Ribbon cassette ERC-27
Interface (compatible) RS-232 serial or IEEE 1284 parallel
Receive buffer 512 bytes or 35 bytes
DKD Function 2 drives
Power supply
*1
DC + 24 V ± 10%
Current consumption
(at 24V)
Operating: Mean: Approx. 600 mA Peak: Approx. 5.5 A
Standby: Approx 100 mA
Life Mechanism: 3,000,000 lines
Print head: 150 million characters (at 2 dots/wire per character)
Ribbon: 1.5 million characters (using a 5 × 7 font)
MTBF 180,000 hours
MCBF 7,000,000 lines
Temperature Operating: 5 to 40°C
Storage: –10 to 50°C, except ribbon and paper
Humidity Operating: 30 to 85% RH
Storage: 30 to 90% RH, except ribbon and paper
Overall dimensions 101.5 × 180 × 190.5 mm
(H × W × D)
Weight (mass) Approximately 1.6 kg
