a. Scanner Unit
b. Ink cartridge holder
c. Print head (under the ink cartridge holder)
a. AC inlet
b.
LAN port
*
c. EXT. port
d. LINE port
e. USB connector
* The availability of this part varies by product.
Guide to the Control Panel
Note:
Although the control panel design and menu and option names and other items in the LCD display may slightly differ from
the actual product, the method of operation is the same.
User’s Guide
Getting to Know Your Product
16
