Confidential
Appendix Protection for Transportation 79
WF-2540 / WF-2530 / WF-2520 / WF-2510 / WF-2010 series Revision B

Singlefunction Printer
Attach the strong tape (3 tapes) to the position on the following diagram and secure the Paper Support/
Paper Support Sub on the Housing Upper Assy.
Figure 6-4. Securing the Paper Support/Paper Support Sub (Singlefunction Printer)
Rear
Paper Support/ Paper
Support Sub
Folded ends
Paper Support/ Paper
Support Sub
Strong tape
