23
TWO-SPEED GEAR CONTROL (E)
The drill has a two-speed gear control designed for drilling or driving at LOW or HIGH
speeds. A slide switch is located on top of the drill to select either LOW or HIGH speed.
When using the drill in the LOW speed range, the speed will decrease and the drill will
have greater power and torque. When using the drill in the HIGH speed range, the speed
will increase and the drill will have less power and torque.
GEAR 1
Low speed range: for screw driving or working with large drilling diameter.
GEAR 2
High speed range: for working with small drilling diameter
BIT FITTING/REMOVING (F)
To t a bit, loosen chuck sleeve to open chuck jaws. Insert the drill bit between the chuck jaws
and tighten chuck sleeve fully. Ensure the drill bit is in the centre of the chuck jaws. To
remove the bit, just loosen the chuck sleeve.
DRILL/SCREWDRIVER/HAMMER SELECTION RING (G)
Three working modes are available on this tool: drilling, screw driving and impact drilling.
To select any of the three modes, rotate the function ring to align it with icon of the drill/
screwdriver/ hammer on the housing, depending on the function you require
.
For screw driving
For drilling in wood and metal
For impact drilling in masonry and concrete
TORQUE ADJUSTMENT (H)
In screw driving mode, the torque can be adjusted by rotating the torque adjustment ring.
Higher number means higher torque. Select the setting as follows:
1 - 4 for driving small screws
5 - 9 for driving screws into soft material
10 - 14 for driving screws into hard wood
15 - 17 for driving larger screws
AUTOMATIC SPINDLE LOCK (I)
The automatic spindle lock allows you to use it as a regular screwdriver. You can give
an extra twist to rmly tighten a screw, loosen a very tight screw or continue working
when the battery energy has expired. For manual screwdriver purposes, the chuck is
automatically locked when the tool is off.
