26
ECSP41
Getting Started . . .
Test run
NOTE: Perform the following test before operating your product. This product
is equipped with an automatic oiling system! The oiling system automatically
delivers the proper amount of oil to the guide bar (2) and saw chain (3).
Checking the lubrication requires starting the engine. Before checking, the
product must be fully assembled and all instructions must have been read.
1. Make sure the guide bar (2) and the saw chain (3) are in place when you check the
oil delivery.
2. Start the engine (as described in section “Starting the engine”); keep it running at
medium speed and check if the chain oil is delivered as shown (Fig. 12).
3. Adjust the chain oil ow by turning the chain oil ow adjuster (22) on the bottom of
the product using the screwdriver (28) (Fig. 13). Turn the chain oil ow adjuster (22)
anticlockwise to decrease the chain oil ow; turn clockwise to increase the chain
oil ow.
12
13
22
28
