20
ECSP51
Getting Started . . .
Before you start
8. Align the tension adjuster pin with the lower hole on the guide bar (2) by turning the
chain tension screw (20) clockwise or anti-clockwise with the multi-tool (24) (Fig. 5).
5
20
24
Tension adjuster pin
2
9. Ret the guard cover (19). Tighten the xing nuts (18) nger tight only at this stage
(Fig. 6).
NOTE: The chain tension cannot be adjusted with the xing nuts (18) fully
tightened.
6
18
19
