In more detail . . .
Hand barrier
> The front hand barrier (7) and rear hand barrier (18) prevent the operator from getting
injured by the cutting blades or ying objects (Fig. 9 and 10).
7
18
9 10
Throttle control lock-out
The throttle control lock-out (2) prevents unintentional start of the throttle control (3). The
throttle control can only be activated if the throttle control lock-out is pressed (Fig. 11).
11
2
3
DANGER! Risk of injury! The equipment must only be put into operation if no
faults are found. If any safety equipment is defective, it must be replaced before
the next use.
