5 TECHNICAL DATA, SIGNALS, DIAGRAMS
5.1 Technical data
CUTTING / AUTO CUT with automatic voltage control
HF voltage waveform unmodulated sinusoidal alternating voltage
Crest factor C, at R
L
=500 ohms C = 1.4 for all settings
Rated frequency 330 kHz
Maximum HF voltage at RL=
∞
600 Vp
Dynamic internal impedance in the rated load range 0 ohms
Cutting quality 4 coagulation effects selectable
Consistancy of 4 coagulation effects automatically controlled
HF rated power 200 watts at R
L
= 500 ohms
HF power limitation 1 to 200 watts in 1 watt steps
Setting the HF power limitation via up/down keys
Display of HF power limitation 7-segment display, 3 decimal places
Precision of the HF power limitation +/- 1 digit or +/- 15%
Automatic power control (PPS) yes
Activation of the cutting mode via key or via pedal
HF connecting sockets 1
CUTTING / ENDO CUT
Applies only to ERBOTOM ICC 200 with Endo Cut
Automatically arc-triggered, fractionated cutting
Basic setting
t
on
= 50 ms,
t
off
= 750 ms
SOFT COAGULATION
HF voltage waveform unmodulated sinusoidal alternating voltage
Crest factor C, at R
L
= 500 ohms C = 1.4 for all setttings
Rated frequency of the HF voltage 330 kHz
Peak value of the HF voltage max. 190 V
p
Constancy of the HF voltage automatically controlled up to P
HFmax.
HF rated power 120 watts at 125 ohms
HF power limitation (P
HFmax.
) from 1 watt to 120 watts in 1 watt steps
Setting of the HF power limitation via up/down keys
Display of the HF power limitation 7-segment display, 3 decimal places
Precision of the HF power limitation +/- 1 digit or +/- 15%
Activation of Soft coagulation via key or via pedal
HF connecting sockets 1
FORCED COAGULATION
HF voltage waveform pulse-modulated alternating current (ST generator)
Crest factor C, at RL=500 ohms C = 5 at 120 Wmax, C = 11 at 5 Wmax
Rated frequency of the HF voltage 1 MHz
Peak value of the HF voltage, Version 1 max. 1300 Vp
Peak value of the HF voltage, Version 2 max. 2300 Vp
Peak value of the HF voltage, Version 3 max. 2300 Vp
HF rated power 120 watts at 350 ohms
HF power limitation from 1 watt to 120 watts in 1 watt steps
Setting of the HF power limitation via up/down keys
Stability of the HF power see diagram Forc. Coag. power via RL
Display of the HF power limitation 7-segment display, 3 decimal places
Precision of the HF power limitation +/- 1 digit or +/- 15%
Activation of the Forced coagulation via key or via pedal
HF connecting sockets 1
