ErGear EGDS2 - Step 2: Clamp Mounting Procedure; Securing the C-Clamp

2A-3 After pushing the clamp fully onto the desk, rotate the knob until the
C-clamp [04] is secured firmly to the underside of desktop.
2A-2 At an angle, guide the C-clamp [04] over the C-clamp brace [03] to desired
position then straighten the C-clamp [04] to be vertical.
0.4 - 3.5"
(10 - 90mm)
0.4 - 3.5"
(10 - 90mm)
Maximum
thickness:
3.5” (90mm)
0101 0101
0303
0404
0404
08
