6. Technical data and dimensions
6.1 Technical specifications
Lifting properties:
Load capacity: 160 kg
Number of lift movements: 60-80 lift with 80kg / 0,5 m
Duty cycle: 10%, max, 2 min/18 min
Manually emergency lowering: Yes
Electronically lowering: Yes
Electrical details:
Power supply (Input): 100-240 VAC 50/60 Hz, max 0,35 A
Output voltage: 24V
Control box (Output): 250 VA
Battery capacity: 2,9Ah
IP-class: IPx4
Noise:
Lwa during lifting/lowering without load is 49dB(A)
Lwa during lifting/lowering at maximum load is 52dB(A)
Material:
Powder coated steel
More test results may be available by contacting Ergolet.
