Cleaning and maintenance
48/64
Upper lamp cover:
– Loosen screws 3-4 mm.
– Take off the lamp cover.
Replacing lamps: see page 46.
Replacing starters: see page 47.
The assembly is the same process in reverse order.
4.10 Cleaning or replacing UV lamps on the
side walls
WARNING!
Acrylic glass panels unusable due to soiling!
Soiling on the panels is burned in by the hot lamps and
results in the long term in unserviceable panels.
– Remove fingerprints and other soiling carefully.
NOTE:
There is a risk of damage being caused to the acrylic glass
panels and the cockpit control and the side walls!
Observe the order: First remove the acrylic cover on the
left and then the one on the right.
Do not knock the right acrylic glass panel against the
cockpit control when removing it.
First remove the left acrylic glass panel:
– Remove the screws.
– Remove the acrylic glass panel and carefully lay it aside.
