ERGOMETRICS ER900 PC - Operating Panel for Manual Control

Operation Manual
Version: 12/01
23
er900 PC Operation Manual
Art-Nr: 475.156
Ergometer
Type er900 PC
Ergometry process
6.5 Operational Panel for Manually Controlled Ergometry
P = 000 W n = 000 /min
HR= 000 /min t = 00 min
S = 000 mmHg D = 000 mmHg
PROG 8 BPM Off PR. Ext
Via the cursor keys, the load can be increased / decreased in steps of Watt. The pos-
sible load covers the range from 20 Watt to 995 Watts.
With the key „Blutdruck I/O“, the blood pressure measurement is enabled „On“ or
disabled „Off“ . The current status is shown on the LCD Display .
With the key „START“, a blood pressure measurement is initiated. Please pay atten-
tion, that a resting BP measurement is required in order to measure the blood pressure
during a stress test.
All further blood pressure measurements have to be initiated manually via the key
“START”.
