Ergomotion MOTION CUSTOM - Base Overview; Quick Reference Guide

4 5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
base overview
Connection ports to
all motors (installed
under base)
Connection to safety
lighting (installed
under the base)
Connection to media
faceplates (installed
under the base)
Sound System (installed
under the base)
Audio Power
Cord
Power Down
Box
9V Batteries
(not included)
Power Cord
Control Box
Power Supply
Input Power
Cord
Massage MotorsPower Down Box Control Box
Safety Lighting
Massage Motors
Head Motor
Foot Motor
Tilt Motor
Speakers
Sub Woofer
Lumbar Motor
VIBRATION
VIBRATION
