Ergomotion Serta Motion Essentials VI - Quick Reference Guide

5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
Power Cord
Power Supply
Wireless
Remote
Head Motor
Foot Motor
Control
Box
ELECTRONICS OVERVIEWCONTROL BOX OVERVIEW
Input
Power Cord
If installing a split unit, see pages 8-9.
Input Power Cord
Connection
Multifunction
port
Head Motor
Port
Foot Motor
Port
Battery Backup
Strap
USB
Chargers
