6
installation guide
STEP 1
STEP 4
STEP 2
Always use two people when setting up the base.
Place the bed base box in a desired location with the bottom of the box
facing up.
Remove the binding straps and packing materials, making sure not to
puncture the box with any sharp objects.
Remove the bed base from the box. Unfold the bed making sure to keep
the bottom of the bed facing upwards.
STEP 3
To sync two bases see detailed installation
instructions on pages 8-9.
To install Headboard Brackets (sold separately)
see instructions on page 11.
It is recommended to leave the battery backup
strap attached to the power supply for use
when needed. 2 9V alkaline batteries (not
included) will be required for its use.
Legs are shipped fully assembled. Alternative heights in 3" increments can
be achieved by removing leg segments.
To install the legs, thread the leg into frame, and tighten by hand. Do not
over tighten.
For customer support, visit www.ergomotion.com or call: 1-888-550-3746
