Ergotron Desktop 16 User Manual

9 of 12
8
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
6
7
888-24-273-G-00 rev D • 12/14
ENGLISH
Connect the USB cable to the USB port.
Place the drawer upside down
and route the USB cable through
the slot on the back of the drawer
and under the hooks toward the
front. Make sure there is no slack
in the cable. All excess cable
should hang from the hooks.
Repeat USB cabling steps 6 through 8
for all remaining cable replacements.

Ergotron Desktop 16 Specifications

Tablet Accommodation

maximum tablet size	10.8 H x 7.7 W x 0.95 in D (27.4 x 19.6 x 1.3 cm)
individual tablet weight	2.2 lb (1 kg)

Power

voltage	100-240 V
current	3.0A
frequency	50/60 Hz

Operating Environment

operating temperature range	0° to 30°C (32° to 86°F)
storage temperature range	-40° to 60°C (-40° to 140°F)
operating relative humidity	10%–90% (non condensing)
storage relative humidity	5%–95% (non condensing)
altitude (maximum)	2000 m (6, 562 ft)

Cooling and Indicators

fan voltage	12-volt DC
fan operation	continuous
LED lights	16

Weight and Dimensions

dimensions	18.3 W x 16.2 D x 10.4 in H (46.5 x 41 x 26.4 cm)
weight	28.5 lb (13 kg)
shipping dimensions	21.2 W x 18.6 D x 12.8 in H (53.8 x 47.3 x 32.5 cm)
shipping weight	33.5 lb (15.0 kg)
rated weight capacity	25 lb (11.3 kg)
