Erickson 07705 - Installation Instructions; Assembly Step 1

Item no: 07705
INSTALLATION INSTRUCTIONS

M8*40Bolt8x
M8Locknut8x
Triangularstop4x
Mountingsleeve4x
Adjustmentknob
4x
CrossBar2x
M10*25bolt12x
1. Slide triangular stop (3) into a mounting sleeve (4), tighten with M8*40 bolt (5) and M8 lock nut (6).
Repeat until all 4 triangular stops are assembled.
