Item no: 07705
2. Tighten Post A (1) and assemble cross bar with M10*25 bolt (7), 10 spring washer (8), 10 washer (17) and
M10 locking nut (16).
3. Tighten Post B (2) and assemble cross bar with M10*25 bolt (7), 10 spring washer (8), 10 washer (17) and
M10 locking nut (16).
4. Position one of the racks on your truck bed, place clamp (10) from downside, tighten with 12 washer (11),
12 spring washer (12) and M12 nut (13). Repeat for the additional 3 posts and clamps.

PostA2x
PostB2x
10washer16x
10springwasher
12x

M10lockingnut
8x
8x
M12nut8x
12Washer
8x
Clamp8x
12springwasher8x
M10*25bolt12x
