Single Radio or Dual Radio on a ceiling (F), see note below for outdoor
installation
•
Single Radio or Dual Radio lying horizontally (G), see note below for
outdoor installation
The installation alternatives described in this section are the primary
installation scenarios for the radio. Flexible installation alternatives are
available for radios installed indoors.
The installation alternatives are shown in Figure 8.
Note:
Figure 8 shows a Single Radio, however the installation alternatives
A, B, C, D, F, and G are similar for Dual Radio.
Figure 8 Installation Method Alternatives
Note:
For mounting direction F or G in an outdoor environment the radio
needs to be protected from direct rain.
Technical Data
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08
13
