Ericsson Baseband 6648 - Power Consumption Details; Power Consumption Values

Condition Value
Operating voltage range −38.0 to −58.5 V DC
Non-destructive range 0 to −60 V DC
Fuse and Circuit Breaker Recommendations
The external fuse and circuit breaker recommendation for the baseband unit is
shown in Table 4.
The recommendations in this section are based on peak power consumption and
give no information on power consumption during normal operation.
The recommended melting fuse type is gG-gL-gD in accordance with
IEC 60269-1. Circuit breakers must comply with at least Curve 3 tripping
characteristics in accordance with IEC 60934.
Table 4 Fuse and Circuit Breaker Recommendations
DC Power Minimum Fuse Rating for
Reliable Operation (A)
(1)
Maximum Fuse Rating
(A)
(2)
Baseband unit 16 20
(1) The recommended fuse rating corresponds to peak load and depends on the conguration.
(2) This value is the internal maximum fuse rating for the unit. General fuse dimensioning have to
take all external factors into account, such as local regulations and cable dimensioning.
3.3.1 Power Consumption
The power consumption values are presented as typical and maximum values,
for a unit with fan. The typical values are based on an air temperature of 20 °C
for the air entering the unit and a typical trafc load. The maximum values are
based on an air temperature of 40 °C for the air entering the unit and a maximum
trafc load.
Note:
The power consumption for SFPs or GPS is not included.
Table 5 Power Consumption
Unit Typical Maximum
Baseband 6648 ≈ 310 W
≈ 340 W
For information on power consumption values see Power Consumption Data and
Power Consumption Calculations.
Baseband Description
6
271/1551-LZA 701 6001/1 Uen A | 2020-04-29
