4 Hardware Architecture
This section contains an overview of the hardware units of the 19-inch baseband
unit.
Figure 4 Baseband 6648 Hardware Architecture
Baseband
Ge19101A
B
A
C
C
Table 6 19-Inch Baseband Hardware Units
Position Name of Units Number of Units
A 19-inch baseband unit 1
B Fan module 1
C Movable Brackets 2
Hardware Architecture
271/1551-LZA 701 6001/1 Uen A | 2020-04-29
7
