Page #16 background image
Main processor AMD® Ryzen™ Embedded V1807B
AMD® Zen™ 4 Cores / 8 Threads, 3.3 GHz (3.6GHz boost)
AMD® Vega™ GPU 2.2 Teraops graphics engine
Memory DDR4-3200 8 GB
Storage 512 GB NVMe SSD (>2 GB/s read speed, >1.5 GB/s write speed)
USB and power 2x USB-C with USB 3.1 Gen 2, DP Alt mode and SuperSpeed+ USB with bi-directional
Power Delivery support
Display output
1x HDMI 2.0b with HDCP2.2 2x DP Alt mode over USB-C
Wi-Fi Mesh 802.11a/b/g/n/ac MIMO 2x2, high output level
Router type EasyMesh™ Wi-Fi standard, MIMO 2x2, high output level 2.4 GHz, 5GHz low band and
separate 5GHz high band
Bluetooth® Bluetooth® 4.2
Ethernet Gigabit LAN and WAN port
Fixed wireless 4G LTE Advanced or 5G 3GPP module (optional)
Access Zigbee (optional)
Smart Home Zigbee (optional)
Voice support 3-microphone far-eld and near-eld voice support
Camera 2x HD cameras with attached computer vision processor (optional)
Remote D-pad, keyboard, and pointer control with rechargeable Li battery and USB charge cable
Electrical rating 100-240 V 1.5 Amax, 50/60 Hz, 95W
Power supply 100W USB-C 1.5 meter cable & detachable 1 meter AC cable
Noise level <28 dBA ISO 7779 ("super quiet") under full load <22 dBA (silent) during media
playback
Expansion slots M.2 slot for NVMe or SATA SSD. USB-A for internal dongle. PCIe for accessories.
Operating
temperature
41 ºF to 95 ºF (5 ºC to 35 ºC)
Dimensions Diameter: 8.50 inch (216 mm), Height: 2.53 inch (64.3 mm)
Weight 5 lbs. (2.3 kg)
Main processor AMD® Ryzen™ Embedded V1807B
AMD® Zen™ 4 Cores / 8 Threads, 3.3 GHz (3.6GHz boost)
AMD® Vega™ GPU 2.2 Teraops graphics engine
Memory DDR4-3200 8 GB
Storage 512 GB NVMe SSD (>2 GB/s read speed, >1.5 GB/s write speed)
USB and power 2x USB-C with USB 3.1 Gen 2, DP Alt mode and SuperSpeed+ USB with bi-directional
Power Delivery support
Display output
1x HDMI 2.0b with HDCP2.2 2x DP Alt mode over USB-C
Wi-Fi 802.11a/b/g/n/ax MIMO 2x2, high output level
Bluetooth® Bluetooth® 5.0
Ethernet Gigabit LAN
Smart Home Zigbee (optional)
Voice support 3-microphone far-eld and near-eld voice support
Camera 2x HD cameras with attached computer vision processor (optional)
Remote D-pad, keyboard, and pointer control with rechargeable Li battery and USB charge cable
Electrical rating 100-240 V 1.5 Amax, 50/60 Hz, 85W
Power supply 100W USB-C 1.5 meter cable & detachable 1 meter AC cable
Noise level <28 dBA ISO 7779 ("super quiet") under full load <22 dBA (silent) during media
playback
Expansion slots M.2 slot for NVMe or SATA SSD. USB-A for internal dongle. PCIe for accessories.
Operating
temperature
41 ºF to 95 ºF (5 ºC to 35 ºC)
Dimensions Diameter: 8.50 inch (216 mm), Height: 2.53 inch (64.3 mm)
Weight 4.73 lbs. (2.15 kg)
Base unit Router unit
