GH688,GA628, Standard Electrical Repairs
4/00021-2/FEA 209 544/1.G 72 (112)
C802-C808 CAPACITOR See revision change table
C810 CAPACITOR RJC 464 3035/33 Verify handsfree mic function
C812 CAPACITOR RJC 464 3035/68 Verify handsfree mic function
C813 CAPACITOR RJE 599 2107/15 Verify handsfree earphone func-
tion
C814 CAPACITOR RJE 599 2107/47A Verify mic function
C815 CAPACITOR RJC 463 3022/33 Verify mic function
C816 CAPACITOR RJC 463 3022/33 Verify mic function
C817 CAPACITOR RJC 463 3022/33 Verify handsfree mic function
C818 CAPACITOR RJC 464 3035/68 Verify mic function
C819 CAPACITOR RJC 464 3035/68 Verify mic function
C820 CAPACITOR RJC 463 3022/33 Verify mic function
C824 CAPACITOR RJC 464 3025/1 Verify display function
C826 CAPACITOR RJA 532 4055/12
C828 Not mounted Not mounted
C829 CAPACITOR RJC 463 3022/33 Verify mic function
C830 CAPACITOR RJC 463 3022/33 Verify mic function
C833 CAPACITOR RJC 464 3035/68
C835 CAPACITOR RJE 599 2107/47A Verify handsfree mic function
C840 CAPACITOR RJC 463 3022/33 Verify earphone function
C841 CAPACITOR RJC 463 3022/33 Verify earphone function
C842 Not mounted Not mounted
C850 CAPACITOR RJC 464 3035/68 Verify mic function
C851 CAPACITOR RJC 464 3035/68 Verify mic function
C853 CAPACITOR RJC 464 3035/68
C854 Not mounted Not mounted
C900 CAPACITOR RJE 599 1108/1W
C902-C907 CAPACITOR See revision change table
C910 Not mounted Not mounted
D600 MICROCIRCUIT See revision change table
D610 MICROCIRCUIT RYT 118 6061/1
D620 MICROCIRCUIT RYT 119 6047/1
D900 FUNCTIONAL
CIRCUIT
See revision change table
E201 SHIELDING POT SXA 120 1194/4
F601 VARISTOR See revision change table Verify handsfree earphone func-
tion
F602 Not mounted Not mounted
GH688
Pos Designation Part No. Note
