GH688,GA628, Standard Electrical Repairs
4/00021-2/FEA 209 544/1.G 93 (112)
C840 CAPACITOR RJC 463 3022/33 Verify earphone function
C841 CAPACITOR RJC 463 3022/33 Verify earphone function
C842 Not mounted Not mounted
C850 CAPACITOR RJC 464 3035/68 Verify mic function
C851 CAPACITOR RJC 464 3035/68 Verify mic function
C853 CAPACITOR RJC 464 3035/68
C854 Not mounted Not mounted
C900 CAPACITOR RJE 599 1108/1W
C902-C907 CAPACITOR See revision change table
C910 Not mounted Not mounted
D600 MICROCIRCUIT See revision change table
D610 MICROCIRCUIT RYT 118 6061/1
D620 MICROCIRCUIT RYT 119 6047/1
D900 FUNCTIONAL
CIRCUIT
See revision change table
E201 SHIELDING POT SXA 120 1194/4
F601 VARISTOR See revision change table Verify handsfree earphone func-
tion
F602 Not mounted Not mounted Verify charging function
F603 VARISTOR See revision change table Verify portable handsfree func-
tion
F604 VARISTOR See revision change table Verify vehicle handsfree function
F605 VARISTOR See revision change table Verify flash function
H600 BUZZER KLJ 107 08/2
H622 Not mounted Not mounted
H624 Not mounted Not mounted
H650 LIGHT EMIT-
TING DIODE
RKZ 433 613/1 Verify red/green top indicator
H651-H654 LIGHT EMIT-
TING DIODE
RKZ 433 641/4 Verify Illumination function
H655-H660 LIGHT EMIT-
TING DIODE
RKZ 433 634/4 Verify Illumination function
J603 COMPONENT
HOLDER
RNK 860 23/04
J810 CONNECTOR2 SXA 120 1210
L213 CHOKE REG 704 4742/12T
L220 INDUCTOR REG 704 4731/56
L230 INDUCTOR REG 704 9542/22
GA628
Pos Designation Product nuber Note
