GH688,GA628, Standard Electrical Repairs

4/00021-2/FEA 209 544/1.G 98 (112)

R823 RESISTOR REP 622 456/1

R825 RESISTOR REP 622 654/33 Verify handsfree mic function

R830 RESISTOR REP 622 453/47 Verify handsfree mic function

R831 RESISTOR See revision change table

R833 Not mounted Not mounted

R834 RESISTOR See revision change table

R900-R905 RESISTOR REP 622 455/1

R906 Not mounted Not mounted

R907 RESISTOR REP 622 456/1

R908 RESISTOR REP 622 456/1

R909 RESISTOR REP 622 456/1

R910 Not mounted Not mounted

U201 TRANSFORMER REG 704 109/1

V220 TRANSISTOR RYN 121 1606/1

V300 TRANSISTOR RYN 901 603/1

V301 TRANSISTOR RYN 120 629/2

V302 TRANSISTOR RYN 121 6069/1

V350 TRANSISTOR RYN 121 6069/1

V351 TRANSISTOR RYN 120 629/2

V400 TRANSISTOR RYN 121 6070/1

V401 TRANSISTOR RYN 121 6070/1

V402 DIODE RKZ 323 650/1

V403 DIODE RKZ 323 650/1

V404 DIODE See revision change table

V405 DIODE See revision change table

V450 TRANSISTOR RYN 120 629/2

V451 TRANSISTOR RYN 120 629/2

V452 TRANSISTOR RYN 120 629/2

V453 TRANSISTOR RYN 122 654/1 Verify charging function

V454 TRANSISTOR RYN 121 6069/1

V502 Not mounted Not mounted

V605 DIODE RKZ 123 647/1

V606 TRANSISTOR RYN 121 6086/1

V607 TRANSISTOR RYN 121 6069/1 Verify ﬂash function

V609 DIODE See revision change table Verify SIM function

V613 TRANSISTOR RYN 121 6086/1 Verify Illumination function

V614 TRANSISTOR RYN 121 6086/1 Verify Illumination function

GA628

Pos Designation Product nuber Note
