II. Specifications
1. Power supply TV: AC 240V, 50Hz
Remote controller BATTERY: 3V (UM-3X2)
2. TV system RF input: PAL BG/DK,SECAM BG/DK
Video input: PAL/ SECAM/NTSC 3.58/NTSC 4.43
3. Receiving channels VHF-L: E2-S10
VHF-H: E5-S41
UHF: E21-E69
4. Intermediate frequencies picture : 38.9MHz
5. Scanning Horizontal (Hz): 15625/15750
Vertical (Hz) : 50/60
6. Socket Aerial input : 75 ohm unbalanced DIN jack
2AV input/1AV out: RCA sockets
Headphone output: ∅3. 5mm stereo jack
7. Color picture tube: North(2) hemisphere Bv=+0.2G ± 0.2G
8. Speaker : 2" ´ 5" 16 ohm 3W ´2 pcs
9. Operating temperature Fulfil all specifications : 15°C ~ 35°C
Accept picture/sound reproduction: 5°C ~ 45°C
10. Operating relative humidity Fulfil all specifications : 45% ~ 75%
Accept picture/sound reproduction: 15% ~ 90%
11. Electrical & optical specification:
No. Items Instruction Typical Limit Unit
1 Video sensitivity For 30dB S/N VL ≤45 ≤48 dBuV
VH ≤45 ≤48 dBuV
U ≤48 ≤51 dBuV
2 FM sound sensitivity For 30dB S/N 30 ≤35 dBuV
3 Synchronizing sensitivity For RF transmission 25 ≤30 dBuV
4 Color sensitivity For RF transmission 32 ≤40 dBuV
5 Teletext sensitivity TV screen refreshes 40 times N/A N/A dBuV
number of mistakes £8
6 Minimum NICAM threshold Without crackline noise N/A N/A dBuV
7 AGC static characteristic Accept. Picture/Sound repr. 103 ≥100 dBuV
8 Selectivity Adjacent sound carrier 40 ≥35
Below adjacent sound carrier 35 ≥30 dB
Adjacent picture carrier 50 ≥40
Up adjacent picture carrier 45 ≥30
9 IF rejection 55 ≥50 dB
10 Image rejection VHF 55 ≥50 dB
UHF 50 ≥45
11 AFT pull-in range M/N N/A N/A MHz
DK/I/BG ±1.5 ≥±1.0
12 Chroma sync pull-in range ±500 ≥±200 Hz
13 Color killer function -25 ≤-16 dB
14 DC restoration 3 ≤10 %
15 Resolution Horizontal PAL/SECAM 320 ≥300
NTSC 270 ≥250
Vertical PAL/SECAM 410 ≥400 lines
NTSC 320 ≥300
16 Overscan Cross hatch signal 93 90~96 %
17 Linearity Horizontal 7 ≤10 %
Vertical 6 ≤8%
18 Pattern distortion 1.5 ≤3%
19 Picture position In all direction ±3 ≤±6 mm
