Erreka SMART-D201 - Complete Programming Chart; Parameter Reference

11
INITIAL NOTES:
F3 menu, trapping force: this parameter must be set to value F31 (for TEMIS and KAIROS operators) or value F32 (for ARES
24V) when programming open/close. After programming open/close, the display shows a figure indicating the current value
multiplied x 10 (showing 10 for 1A, 20 for 2A, etc).
F9 menu: the exterior photocell (FT1) only works during closing.
The interior photocell (FT2) works both during opening and closing.
The voltage output for the 24 VDC flashing light is intermittent (FB menu).
The flashing light used should therefore be configured in static mode.
Change the FC0 parameter to FC1 to enable the exterior safety photocells (FT1).
Change the FD0 parameter to FD1 to enable the interior safety photocells (FT2).
Menu Description Options
Preset
option
Options or values
F1 Encoder / Limit switches F11 F11 F11: not installed
F12 F12: with limit switches
F13 F13: with single encoder
F2 Number of operators F21 F21 F21: two operators
F22 F22: one operator
F3 Maximum trapping current:
Select F31 while programming
TEMIS and KAIROS.
Select F32 while programming
ARES 24V.
F31 F31 F31: 2A
F32 F32: 3A
F33 F33: 4A
F34 F34: 5A
F4 Gate speed F41 F41 F41: 100% of maximum speed
F42 F42: 80% of maximum speed
F5 Slowdown F51 F51 F51: slowdown in opening and closing
F52 F52: no slowdown
F6 Slowdown speed F61 F62 F61: 70% of maximum speed
F62 F62: 50% of maximum speed
F63 F63: 35% of maximum speed
F64 F64: 25% of maximum speed
F7 Lapse between leaves in
opening and closing
F71 F71 F71: 2 seconds
F72 F72: 3 seconds
F73 F73: 4 seconds
F74 F74: 5 seconds
F75 F75: 6 seconds
F76 F76: 7 seconds
F77 F77: 8 seconds
F78 F78: 9 seconds
F79 F79: 10 seconds
F8 Automatic or step-by-step
operation mode and standby
time (in seconds) in automatic
mode
F80 F80 F80: Step-by-step mode
F81 F81: Automatic mode and stand-by time 3s
F82 F82: Automatic mode and stand-by time 10s
F83 F83: Automatic mode and stand-by time 20s
F84 F84: Automatic mode and stand-by time 40s
F85 F85: Automatic mode and stand-by time 60s
F86 F86: Automatic mode and stand-by time 120s
F87 F87: Automatic mode and stand-by time 180s
F88 F88: Automatic mode and stand-by time 300s
F9 Functions of FT1-FT2 F91 F91 F91: FT1 exterior photocell, FT2 interior photocell
F92 F92: FT1 exterior photocell, FT2 safety strip
F93 F93: FT1 exterior photocell, FT2 opening device
F94 F94: FT1 photocell interlock, FT2 interior photocell
Complete programming chart
