SECTION 7 Replacement Parts
ESP 600C Plasma Power Source
7-7
Item No Qty Part Number Description Circuit Symbol
1 1 35717 Transformer Control T2
2 2 674969 PCB Filter FN1,2
3 4 950704 RECT SIL Reverse 85A D29,30,35
4 3 950703 RECT SIL Forward 85A D31,32,34
5 1 973168 Terminal Strip 13 pos TB7
6 7 17300008 Resistor 8 OHM 300W R12-17,24
7 6 17300001 Resistor 1 OHM 300W R1-3,21-23
8 3 17300004 Resistor 4 OHM 300W 18-20
9 1 35750 Panel Rear
10 1 35710 Inductor L2
11 1 0558002525 Potted Resistor Assembly PRA1
12 6 950631 PC Board Support
