SECTION 7 Replacement Parts
ESP 600C Plasma Power Source
7-17
Item No Qty Part Number Description Circuit Symbol
1 6 17280210 Resistor 1k ohms 100W R10,11,28-31
2 4 2080196 Relay 3 pos brkt MT K3,5,6,7
3 1 0558004783 Terminal Block 18 pos TB8
4 10 13730638 Diode Rectifier Reverse 800V 300A D7-12,25-28
5 6 13730639 Diode Rectifier Forward 800V 300A D13-18
6 1 950711 Switch Thermal 194 DegF TS7
7 2 35710 Inductor L1,2
