4 TECHNICAL DATA
0458 870 201
- 8 -
© ESAB AB 2014
Welding torch PSF 250 PSF 315C LD PSF 405C
PSF 405C RS3
PSF 410Cw
410Cw RS3
Wire diameter 0.6-1.0 mm 0.8-1.2 mm* 1.0-1.6 mm 0.8-1.6 mm
Weight 3.0 m hose
package
3.5 kg 4.3 kg 4.6 kg 4.0 kg
Weight 4.5 m hose
package
5.0 kg 5.4 kg 6.8 kg 6.2 kg
* Not recommended for 1.2 mm aluminium wire
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or
cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F.
Liquid cooled torches PSF 410w, PSF 410w RS3, PSF 510w, PSF 510w RS3,
PSF 410Cw, PSF 410Cw RS3
Type of cooling 50% water and 50% ethylglykol
Pressure max. 3.5 bar
Pressure min. 2.0 bar
Temperature max. 50°C
Flow 1.0 l/min
