41
Using BIOS
Onchip USB (V1.1+V2.0)
This item enables users to enable or disable the onchip USB function, setting it to be USB1.1
or USB2.0 compatible.
Onboard Device Setup (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
Phoenix-Award WorkstationBIOS CMOS Setup Utility
Onboard Device Setup
Item Help
Menu Level
Onchip USB [V1.1 + V2.0]
USB Memory Type [SHADOW]
USB Keyboard Support [Enabled]
USB Mouse Support [Enabled]
HD Audio [Auto]
Onboard Lan [Enabled]
Onboard Lan Boot ROM [Enabled]
MAC Media Interface [Pin Strap]
Machine MAC(NV) Adress [Press Enter]
x
F5:Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
MAC Media Interface (Pin Strap)
This item is used to select MAC Media interface.
Machine MAC(NV) Adress (Disabled)
Enable this field to enter the MAC(NV) address in the field below.
USB Mouse Support (Enabled)
Enable this item if you plan to use a mouse connected through the USB port in a legacy
operating system (such as DOS) that does not support Plug and Play.
HD Audio(Auto)
Enables and disables the onboard audio chip. Disable this item if you are going to install a
PCI audio add-in card.
Onboard Lan (Enabled)
Enables or disables the Onboard Lan.
USB Memory Type (SHADOW)
This item indicates the USB memory type.
USB Keyboard Support (Enabled)
Enable this item if you plan to use a keyboard connected through the USB port in a legacy
operating system (such as DOS) that does not support Plug and Play.
Onboard Lan Boot ROM (Disabled)
This item enables or disables LAN Boot ROM.
Machine MAC(NV) Adress(Press Enter)
Move the cursor to this item and then fill in the MAC(NV) adress.
Press <Esc> to return to the Integrated Peripherals page.
