3
Introducing the Motherboard
Onboard LAN (Optional)
The onboard LAN provides the following features:
This motherboard supports Ultra DMA bus mastering with transfer rates of 133/100/66
MB/s.
:
• One PCI Express x16 for Graphics Interface (MCP61S only support PCI
Express x8)
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• One IDE connectors supporting up to two IDE devices
• One floppy disk drive interface
• Two 7-pin SATA2 connectors
Expansion Options
Integrated I/O
The motherboard comes with the following expansion options:
1394a FireWire (Optional)
• Compliant with single chip host controller of IEEE Std 1394-1995 and IEEE
1394a-2000
• Integrated 400 Mb/s 2-port PHY for the PCI BUS
• 3.3V Power Supply with 5V Tolerant Inputs
The motherboard has a full set of I/O ports and connectors:
• Two PS/2 ports for mouse and keyboard
• One serial port
• One parallel port
• One VGA port
• Four USB ports
• One LAN port (optional)
• One 1394a port (optional)
• Audio jacks for microphone, line-in and line-out
BIOS Firmware
The motherboard uses Award BIOS that enables users to configure many system features
including the following:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
The firmware can also be used to set parameters for different processor clock speeds.
Some hardware specifications and software items are subject to change
without prior notice.
• Supports 10 Mb/s and 100 Mb/s N-way Auto-negotiation operation
• Supports Wake-on-LAN function and remote wake-up
• Half/Full Duplex capability
• Integrated 10/100/1000 transceiver
• Supports PCI rev.2.3,32-bit,33/66 MHz
• Crossover Detection & Auto-Correction
• Wake-on-LAN and remote wake-up support
• 10BASE-T/100BASE-TX IEEE 802.3u fast Ethernet transceiver
• Low-power mode
• MII and 7-wire serial interface
