Assembly Instructions - Installing the Hinges
1.
On a dry and clean surface place a Target Board (#1) facing down, locate the pre-
drilled holes and attach Hinges (#3) with Screws (#11). See Figure 1 & Detail A.
A
-4-
Figure 1.
3
1
11
NOTICE
FOR CORRECT & PROPER
INSTALLATION PLEASE MAKE
SURE TO INSTALL HINGES (#3)
USING THE PRE-DRILLED HOLES
FOR STEP 4 (SEE NEXT PAGE).
To Next Page
