8 Seare Instruction Manual
7
Rudder.
Aluminium Washer.
CONTROL HORN
M3 SCREW.
M3 LOCK NUT.
Epoxy.
Aluminium Washer.
Fuselage.
Fuselage.
18mm.
Epoxy.
Rudder.
INSTALL RUDDER CONTROL HORN
1 sets.
3x50mm.
Elevator control horn.
3mm.
Repeat steps to install the rudder control horn
as same as steps done for ailerons.
Aluminium Washer.
CONTROL HORN
M3 SCREW.
M3 LOCK NUT.
Epoxy.
Aluminium Washer.
Elevator.
Horizontal
Stabiliser.
18mm.
Epoxy.
Elevator.
Horizontal
Stabiliser.
Rudder control horn.
