 Distance from Fireplace to Fascia Base
The installaon requires a spacer below the appliance to allow room for the fascia to sit ush with the non
combusble oor or a hearth.
The following side-on view shows the measurement from the base of the replace to the base of the fascia:
END OF SECTION B

 A framed false cavity OR
 
28
Slim Fascia &
Stretch Fascia
Fire
Base
52
Edge Fascia
Fire
Base
28
Slim Fascia &
Stretch Fascia
Fire
Base
52
Edge Fascia
Fire
Base
Spacer
55mm
Edge Fascia
Spacer
30mm
Slim Fascia &
Stretch Fascia
