Escea DF700 - Flue Configuration (More than 4 m)

C
18

If your ue system is greater than 4m long (as shown in diagrams below), then there are the following opons:
ͳ DFS Only: Flexible ue with condensate trap and rigid PolyPro tube lengths (see diagrams below).
ͳ DF: For ue run installaons beyond 4m and up to 12m, exi ue must be used for the enre ue run and
must be fully insulated from appliance connecon to fan unit. For informaon on the insulaon installaon
see secon C10 on page 28. Beyond 12m (up to 40m) please contact the Escea Advisory Team at aa@
escea.com.
Up to 12m MAX
UVP Fan Unit
1.2m F-F Liner
Ø75mm / Ø100mm
Flexible flue
Insulation
Covering entire
flue length
Fireplace
Up to 12m MAX
Escea Wall
Terminal
Ø75mm / Ø100mm
Flexible flue
Insulation
Covering entire flue length
Fireplace
