Escea DF700 - Installing the Internal Vertical Power Flue

C
23
C5 
Note: Internal install is only recommended for situaons where an external install is
unpraccal. For informaon regarding an external install of the UVP, go to secon C4
on page 22.
The Universal Vercal Power Flue (UVP) internal conguraon is designed to have the
fan, mounted within the roof space of the house, and the vercal Ø225mm diameter
liner, containing a Ø100mm exi, penetrate through the roof. The UVP internal
conversion kit comes with a 1200mm liner that is specic to the internal installaon
and must always be used.
Note: The ue setup must comply with secon C1 on page 15 or C2 on page 17
Use standard methods to ash the roof penetraon. The installaon must be
weatherproof and conform to all local council standards including powered ue
terminaon rules.
Mount the fan mount bracket (1) to the roof framing and strapping using mber
ensuring that the ue is rigid and vercal. Ensure that the mounng mber does not
obstruct access to the 3xM5 screw threads on the side of the fan unit.
Aim to have the fan enclosure (2) mounted as high as possible, mainly to allow
sucient fall for condensaon drainage if the exi-ue is to run horizontally.
Ensure there is sucient space below fan enclosure (2) to have access to t the exi-
ue tubes (3) and allow owing bends if required.
The new DF700 and DF960 res need to be paired with a specic ue restrictor to work as intended, some UVP
units will already have this installed, if that is the case then all that is needed is to pop out the restrictor shown
in gray so that only the “43” is showing.
(1)
(2)
(3)
