C
24
Note: The UVP-Internal and the exi ue connecons must be installed in a locaon accessible for service or
replacement; a service hatch or removable ashing to allow access is required.
Note: When installing the unit onto a ue liner, ensure the length of ue liner above the roof is the minimum
required length.
The UVP-Internal kit is intended for use within an accessible roof space or ‘chimney’ construcon.
Ensure installaon complies with relevant building codes and regulaons.
290
229.1
ø226.8
31.6
221.8
250.2
31.6
103.4
TIMBER MUST NOT
OBSTRUCT THESE ZONES
To appliance
UVP Cowl
‘Decktite’ or similar ashing
1.2m F-F Liner
Hose band clamps
Ø75mmØ100mm
Ensure Power Flue unit
is securely braced using
integral brackets.
Roof Space
Power cord to
appliance
UVP Fan Unit
