Escea DF700 - Masonry Vertical Power Flue Kit (up to 6 m)

C
25
C6 
The following kit enables the installaon of the aluminium exi into vercal masonry chimneys for extending
the ue system from the appliance spigot to 6.0 meters while providing the masonry ashing.
Including, but not limited to, installaons into: a complete masonry chimney, a ue liner, or a combusble
sealed false chimney.
If your ue system is to be run vercally through a purpose-built sealed ue cavity (the cavity must remain
sealed up to the terminal); PolyPro and a condensate drain is not required. An extension kit can be purchased to
extend the maximum length to 12m, see secon C7 on page 26. Only the Universal Vercal Power Flue (UVP-
External) kit can be used for this installaon type.
Note: 225mm wide x 240mm long 906624-Masonry ue liner extension kit can be purchased to add extra
protecon for the high snow and rainfall areas.
Note: If any gap occurs in between the 400mm x 400mm masonry ashing and the chimney due to the
chimney dimensions, the suitable chimney cap ashing can be built as keeping the spigot diameter 225mm.
6m Max
Ø75mm ID / Ø100mm ID
Flexible Flue
Purpose-built Sealed
Flue Cavity
Universal Vertical
Power Flue (External)
Masonry
Flashing
Chimney
