Escea DF700 - Masonry Vertical Power Flue Extension Kit (6 to 12 m)

C
26
C7 
The following kit enables the installaon of the aluminium exi into vercal masonry chimneys for extending
the ue system to 12.0 meters from the Masonry Vercal Power Flue kit that is required and supplemented by
the 12m Masonry Vercal Power Flue Extension Kit.
Including, but not limited to, installaons into: a complete masonry chimney, a combusble sealed false
chimney.
NOTE: This installaon type cannot be used on a DFS730. If required, please contact architectural advisory aa@
escea.com for more informaon.
If your ue system is to be run vercally through a purpose-built sealed ue cavity (the cavity must remain
sealed up to the terminal); PolyPro and a condensate drain is not required. Only the Universal Vercal Power
Flue (UVP-External) kit can be used for this installaon type.
The exhaust/inlet ue MUST BE NO longer
than 12.0M.
The 100mm ue shroud must cover the
enre length of the exhaust ue.
The intake and shrouded exhaust ue
must be enrely enclosed within a fully
vercal masonry or purposely constructed,
a combusble sealed cavity/masonry
chimney.
Feed the power ue cable down through
the chimney cavity and connect to the
appliance and Power Flue.
NOTE: This kit supplements and requires 906602-Masonry vercal Power Flue kit.
Note: If any gap occurs in between the 400mm x 400mm masonry ashing and the chimney due to the
chimney dimensions, the suitable masonry ashing can be built as keeping the spigot diameter 225mm.
6m to 12m
Ø75mm ID exhaust with
Ø100mm ID shield
Flexible Flue
Ø75mm ID Inlet unshielded
Flexible Flue
Transition Spigot
100mm ID Flexible Flue
75mm ID Flexible Flue
non-combustible
sealed flue cavity
Universal Vertical
Power Flue (External)
Masonry
Flashing
Chimney
