Escea DF700 - Installing in Accordance with Relevant Codes

C
27
C8 Installing in Accordance with Relevant Codes
The locaon of the Horizontal Power Flue Wall Terminal must be installed in accordance with AS/NZS 5601 and
any other relevant building codes. If possible, avoid installing the Horizontal Power Flue Wall Terminal in areas
exposed to high winds and extreme weather.
Some of the minimum clearances for a fan assisted wall terminal are listed below; please refer to AS/NZS 5601
Gas installaon standard for full guidance on the design of the ue system. Where possible allow a greater
clearance.
A Below eaves, balconies and other projecons 200mm
B From the oor, above a balcony or other surface 300mm
C From a return wall or external corner 300mm
D From a gas meter or regulator vent 1000mm
E From electricity meter or fuse box 500mm
F From a drain pipe or soil stack 75mm
G Horizontally from any building structure or obstrucon 500mm
H From any other ue terminal or combuson air intake 300mm
J Horizontally from any openable window, door, non-mechanical air inlet, or any
other opening into a building with the excepon of sub oor venlaon
300mm
K From a mechanical air inlet or spa blower 1000mm
L Vercally below any openable window, door, non-mechanical air inlet, or any
other opening into a building with the excepon of sub oor venlaon
300mm
N Horizontally from a roof light 600mm
O Vercally from a roof light 500mm
Q Vercally from a at roof 500mm
R Horizontally from a vercal structure 500mm
S Below a roof window 2000mm
T Above or either side of a roof window 600mm
U From a dormer window 1500mm
V Above the apex of the roof (see note 1 on following page) 300mm
W From an open ue 1500mm
N
R
F
S
W
U
A
V
K
Q
E
J
J
A
H
E
D
C
C
A
O
G
J
L
B
M
P
M = Gas Meter
P = Electricity meter or Fuse box
Prohibited area for ues is below or Distance ‘E’ to the
left and right of the Electricity meter or fuse box
H
