Note: Make sure to turn o the power supply before connecng the power ue cable. Feed the Power Flue
cable through the silicone grommet on the lower right hand side of the chassis and connect it to the terminal
on the electronics tray shown in the diagram below.
Note: the burner tray must be removed to access the electronics tray as shown in secon E3 on page 35.
Test the fan now to ensure that it will run prior to connuing with installaon. Failure to plug in the fan will
result in an error code when starng the replace.
E5 Fixing the Appliance to the Base
An appropriate fastening can be screwed down to the cavity base through the 4 circled holes in the diagram.
ENSURE THAT THE FIRE IS SEISMICALLY RESTRAINED IN A MANNER APPROPRIATE TO THE INSTALLATION
