Note: The regulator that is supplied with the re MUST NOT BE REMOVED. Removal of the regulator, or
replacing it with one not intended for use with an Escea re, will void the limited appliance warranty.
The gas connecon on the appliance regulator is a ½” female
BSPP at the front right of the appliance; the regulator is located
on the underside of the main burner tray (circled le). The gas
supply secon of the piping will need to be exible inside the
chassis to allow for pipe disconnecon and burner tray removal.
With the burner tray out, the exible gas supply pipe may
be bent into posion to align with the regulator connecon
point when the burner tray is replaced. The gas supply can be
ghtened onto the regulator through the access hatch shaded in
the diagram below.
E7
As per AS/NZS 5601 it is recommended that a gas isolang valve be installed prior to the inlet of the re for
servicing in the future.
It is recommended to install a gas isolang valve as close to the appliance as possible when installing your Escea
gas product. Fix it in a convenient posion to allow it to be closed easily during operaon. Consider access once
wall linings have been xed. In some instances, a gas isolaon valve will not be able to be ed due to physical
limitaons and access points. In such a situaon it is acceptable to place a valve closer to the gas meter or use
the gas meter as the isolang valve during service work and install.
E8 Pressure Test Point
As per AS/NZS 5601, a pressure test point shall be provided by the installer prior to the inlet of the appliance.
E9
Run the heater on full (both burners running) and measure inlet pressure with all the other gas appliances
