 Replace the test point hatch
 Flame Picture
An abnormal ame paern will look long and stringy and may cause soot to build up inside the rebox.
An abnormal ame paern will likely be the result of incorrect sengs (jet size, burner aeraon collar, ue
restricon), and if present you must check these are correct before proceeding.
Note: When checking ame picture ensure burners fully light on ignion, build up of embers or large embers
can impede and cause breaks in the cross-lighng.
If an abnormal ame paern is sll present or cross-lighng is an issue, please contact Escea.
It is the responsibility of the installer to ensure a correct ame paern.
Note: The fuel bed instrucons contain necessary informaon on installing the fuel bed, retain this instrucon
sheet for future servicing.
