Escea DF700 - Converting Appliance Gas Type; Removing or Cleaning Fan

S
55
S6 
If there is a need to convert the gas type of the appliance, follow the instrucons provided with your gas
conversion kit using the following table for correct jets and collars:
For Natural gas res a silver spring is installed in the regulator and Propane and ULPG use a purple spring.
DF700 ONLY
Jets Front Burner Rear Burner Aeraon Collars Pilot Jet
NG Ø 1.6 mm Ø 1.40 mm Front 1 x 4mm, Rear 2 x 4.5mm #42
Propane Ø 1.05 mm Ø 0.85 mm Front 2 x 8mm,Rear 2 x 8mm #27
ULPG Ø 1.05 mm Ø 0.85 mm Front 2 x 12mm, Rear 2 x 13mm #27
DF960 ONLY
Jets Front Burner Rear Burner Aeraon Collars Pilot Jet
NG Ø 1.9 mm Ø 1.40 mm Front 1 x 4mm, Rear 1 x 4mm #42
Propane Ø 1.20 mm Ø 1.05 mm Front 2 x 11mm, Rear 2 x 13mm #27
ULPG Ø 1.20 mm Ø 1.05 mm Spacer Collars #27
S7 Removing or Cleaning Fan
As part of regular service procedure, it is recommended that the fan is removed for cleaning. Dust will build up
on the fan rotor and in the cavity where the fan is located. This can be removed by the service person using a
hearth brush and a vacuum cleaner.

Remove the electronic tray located on the base of the chassis (instrucons provided in the next secon) before
aempng to remove the room air fan. Disconnect the 3-way fan connector and remove the two screws circled
in the diagram below. The room air fan can now be pull towards you and removed through the burner tray hole.
