Hardware component instructions of the ES206 IP Phone are:
ITEM DESCRIPTION
1 LCD Screen Displayed information about calls, messages, soft keys, time, date and
other relevant data:
• Call information — caller ID, call duration
• Icons (e.g.
)
• Missed calls or second incoming caller's information
•Time and date
2 Line Key Red, flashing: Incoming call
Red, steady: Pick up but not on communication
Green, steady: On communication
Green, flashing: On hold
Light off: Idle
NOTE: Light yellow steady: Under the idle status, the light will on
when:Missed Call, Transfer, DND, Message, Mute,SIP-Unregistered.
3 Soft Key Labels automatically to identity their context-sensitive features
4 Navigation
Key&Volume Key
In the idle status, press UP or DOWN key can check the call log:
UP: Open the "All CONTACT LOG",DOWN: Open the "MISSED CALL",
RIGHT and LEFT can check other list, like "RECEIVED CALL\DAIL CALL".
In the idle or talking status, press RIGHT or LEFT key can adjust the
volume.
5 Mute & C Key Cancels actions or rejects an incoming call, and the other feature:
In the idle: Open the "Phone Status".
Diagnosis: Press and hold 3 second to open "Hardware Diagnosis".
MUTE: "MUTE" feature is enabled if you press it while the conversation
making on the phone.
6 Redial Key
Dial the latest number.
7 Programmable
Key
In the idle status, press and hold 3s will enter programmable function,
the default password is empty:
Line 1 & 2: press and hold can quickly enter account setting. If you
want set it to another function, you need to login into website to
change it.
Navigation key UP & DOWN, Redial key press and hold can quickly
enter programmable key setting function, they can change to
Redial\DND\Personal Phonebook\Enterprise Phonebook\LDAP
\Directory\Speed Dial\Call History\Received Calls\Dialed Calls\Main
Menu\New Message\Forwarded Calls\View Status\Enable/Disable SIP
Account\Default.
NOTE：MUTE&C key isn’t support programmable function.
8 Speaker Key Toggles the hands-free speaker phone mode.
Press and hold can
change to headset mode
9 MIC High sensitive pickup Mic.
