ESI ES3247 - Programmer Installation; Post-Installation Commissioning

4. Set backlight either permanently ON or OFF in accordance with
customer requirements (refer to Seng the Backlight, page 9).
5. Leave these installaon instrucons with customer for
15
Switch on mains supply. Referring to the user guide:
1. Use the buons to ensure correct product funconality.
2. Set ming and programme details in accordance with customer
requirements.
3. Normally unit will be le with channel in ‘Auto’ mode.
Fing the Programmer
1. Loosen the two ‘capve’ retaining screws on
the boom of the back plate.
2. Now fit the programmer to the back plate,
ensuring the lugs of the back plate engage with
the slots on the programmer.
3. Swing the boom of the programmer into
posion ensuring the connecon pins on the
back of the unit locate into the terminal slots in
the back plate.
Commissioning
4. Tighten the two ‘capve’ screws to fix the unit securely.
